American LandMaster EV - 4X2
|Model:||EV - 4X2|
|Type:||Utility / Side-by-Side|
PDFs / Files
Request More Info
American LandMaster EV - 4X2
Please enter your contact information and one of our representatives will get back to you with more information.
Bring something bold and different home this year. The lithium-powered EV is the perfect, maintenance-free side-by-side to help tackle chores, enjoy times with friends, transport material around your property, or just enjoy a quiet ride around your community.
Thanks to our unique L-ROSS (Landmaster Ride Optimization Suspensions System) you'll barely notice the rumble strips, railroad ties, or large rocks you just plowed over. Your life will get a whole lot easier knowing you can tackle heavy jobs, loaded trails, tight corners, and muddy trails. Plus, you'll have added comfort even in the most uncertain environments due to our unique coil over shock setup and supersport trailing arm.
POWER AC motor, powered by a 48V DC Lithium-Ion Battery at 12K Watts with 600 amp Navitas controller (6.7 HP for long term driving, 16 HP for short term peak with 160 Amp Hour Battery)
SPEED Up to 30 mph (12 mph in the MAX DISTANCE mode)
RANGE Up to 45 miles (in MAX DISTANCE mode) with 105 AH battery 65 degrees) Up to 60 miles (in MAX DISTANCE mode with 160 AH battery 65 Degrees)
STARTING Keyed on/off
ALTERNATOR Converter / 30 amps
TRANSMISSION Direct drive
TRANSAXLE H-12 Schafer / DANA gearbox
DIFFERENTIAL Limited Slip Dierential
DRIVE 2 wheel drive
FRONT SUSPENSION Double A-arms, adjustable coil over shock with up to 8" travel
REAR SUSPENSION Independent trailing arm, with radius rod, adjustable camber & tow control, dual-rate coil over shock with up to 8" of travel
BRAKE SYSTEM 4 wheel disk, hydraulic brake. Trans-axle mounted rotor with mechanical caliper parking brake with indicator light.
TIRES 25'' DOT On Road / On Road Tire (8'' front 10'' back)
DIMENSIONS 110'' L x 58'' W x 76'' H
WHEEL BASE 73.5''
TURNING RADIUS 13' inside radius
GVRW HD-LROSS - 3,025 lbs.
CURB WEIGHT 1350 lbs. with 105 AH battery
BED MATERIAL Structural foam ''Poly Bed'' with stake pockets
BED DIMENSIONS 35.25'' L x 41.5'' W x 11'' D
GROUND CLEARANCE 11"
BED CAPACITY L-ROSS - 500 lbs. / HD-LROSS - 700 lbs. Poly - 9 cu.ft. / Steel - 11 cu.ft.
TOTAL PAYLOAD L-ROSS - 900 lbs. / HD-LROSS - 1,100 lbs.
